Specifications

Continued from previous page

Storage

∙ 

∙ 

ASM1061)

∙ 5x M.2 slots (Key M)

▪ M2_1 slot (From CPU)

▫ Supports PCIe 4.0 x4

▫ Supports 2260/ 2280/ 22110 storage devices

▪ M2_2 slot (From Z690 Chipset)

▫ Supports PCIe 4.0 x4

▫ Supports 2260/ 2280 storage devices

▪ M2_3 slot (From Z690 Chipset)

▫ Supports PCIe 4.0 x4

▫ Supports 2242/ 2260/ 2280/ 22110 storage devices

▪ M2_4 slot (From Z690 Chipset)*

▫ Supports PCIe 3.0 x4

▫ Supports SATA 6Gb/s

▫ Supports 2242/ 2260/ 2280 storage devices

▪ M2_5 slot (From Z690 Chipset)

▫ Supports PCIe 4.0 x4

▫ Supports SATA 6Gb/s

▫ Supports 2260/ 2280 storage devices

▪ M2_2~5 support Intel® Optane™ Memory

∙ Supports Intel® Smart Response Technology for Intel

Core™ processors

* SATA7 will be unavailable when installing M.2 SATA SSD in the M2_4 slot.

RAID

∙ Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA

storage devices*

∙ Supports RAID 0, RAID 1 , RAID 5 and RAID 10 for M.2

NVMe storage devices

* SATAA & SATAB do not support RAID function.

Continued on next page

MSI MPG Z690 CARBON WIFI Specifications

General

Form Factor	atx
Chipset	z690
Chipset Compatibility	intel
Processor Socket	socket lga 1700
Processor Compatibility	intel, intel core i9, intel core i7, intel core i5, intel core i3
RAID	raid 0, raid 1, raid 5
Multi-GPU	crossfire
Memory Type	ddr5
Memory Speeds	6666
SATA Connectors	6x sata 6g
Wireless Standard	ax
Wireless Networking Standard	wi-fi 6e
Wireless Connectivity	bluetooth, wi-fi
USB Ports	6 x usb-a 3.2, 1 x usb-c 3.2, 4 x usb-a 2.0
Audio Ports	1x front audio (jaud)
Audio Channels	8
M.2 Slots	5
