8
Network Standard Bluetooth v2.1 Class II +EDR
Frequency Band 2.400 - 2.4835 GHz
Data Rate Up to 3Mbps
Channel 79 sub-channels
Transmission FHSS (Frequency Hopping Spread
Spectrum)
Modulation n/4 DQPSK@2Mbps, 8DQPSK@3Mbps
Antenna Type PCB printed antenna
Power Consumption 66mA in continuous Tx
8.6mA in standby mode
Max. Output Power -4~4 dBm
Max. Input Level -20 dBm@BER<0.1%
Receiver Sensitivity -82dBm @ BER<0.1%
Range Up to 10 m operating range
(outdoor operating range)
Physical Links Support ACL and SCO link
Network Capabilities Support piconet point-to-point and
point-to multipoint connections
Link Manager 3-slot Packets: Yes
5-slot Packets: Yes
Slot Offset: Yes
Timing Accuracy: Yes
Switch: Yes
Hold Mode: Yes
Sniff Mode: Yes
Test Mode: Yes
Park Mode: Yes
RSSI: Yes
Power Control: Yes
Authentication: Yes
Encryption: Yes
Bluetooth
Specification
