MSI MS-6570 - Page 110

B-4
MS-6570 ATX Mainboard
2. Connect the other end of the RCA cable to the TV.
1. Connect one end of the RCA cable to the TV-Out(C) connector. The RCA
cable usually comes with three connecotrs on both ends. The white or red
connector is for audio while the yellow one is for video.
Connecting RCA cable
White (Audio)
RCA cable
Yellow (Video)
Red (Audio)
Yellow (Video)
Yellow (Video)
