2-13
Hardware Setup
Serial ATA Connector: SATA1/ SATA2/ SATA3/ SATA4/ SATA7
(SATA3 and SATA4 are optional)
This connector is a high-speed Serial ATA interface port. Each connector can con-
nect to one Serial ATA device.
SATA3
(Optional)
SATA4
(Optional)
SATA1 SATA2
SATA7
Important
Please do not fold the Serial ATA cable into 90-degree angle. Otherwise,
data loss may occur during transmission.
