BIOS Setup
Device/ Vendor/ Size
It will showing the device information that you connected to the SATA connector.
LBA/Large Mode
This allows you to enable or disable the LBA Mode. Setting to Auto enables LBA
mode if the device supports it and the devices is not already formatted with LBA
mode disabled.
DMA Mode
Select DMA Mode.
Hard Disk S.M.A.R.T.
This allows you to activate the S.M.A.R.T. (Self-Monitoring Analysis & Reporting
Technology) capability for the hard disks. S.M.A.R.T. is a utility that monitors
your disk status to predict hard disk failure. This gives you an opportunity to
move data from a hard disk that is going to fail to a safe place before the hard
disk becomes offline.
SATA1~6 are appearing when you connect the HD devices to the SATA con-
nector on the mainboard. Due to the IDE1 & SATA7 is controlled by Marvell
88SE6111, the BIOS will not detect the IDE & SATA device and will
not show the status.
Important
