MSI MS-7846 - Internal Connectors; BIOS Features; Form Factor

English
13
Internal
Connectors
󰀲 1x 24-pin ATX main power connector
󰀲 1x 4-pin ATX 12V power connector
󰀲 2x SATA 6Gb/s connectors
󰀲 2x SATA 3Gb/s connectors
󰀲 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
󰀲 1x USB 3.0 connector (supports additional 2 USB 3.0 ports)
󰀲 1x 4-pin CPU fan connector
󰀲 1x 4-pin system fan connector
󰀲 1x Front panel audio connector
󰀲 1x Serial port connector
󰀲 1x TPM connector
󰀲 2x System panel connectors
󰀲 1x Chassis Intrusion connector
󰀲 1x Clear CMOS jumper
BIOS
Features
󰀲 UEFI AMI BIOS
󰀲 ACPI 5.0, PnP 1.0a, SM BIOS 2.7, DMI 2.0
󰀲 Multi-language
Form Factor 󰀲 Micro-ATX Form Factor
󰀲 9.1 in. x 6.8 in. (23.1 cm x 17.3 cm)
For the latest information about CPU, please visit
http://www.msi.com/cpu-support/
For more information on compatible components, please visit
http://www.msi.com/test-report/
