MSI MS-7846 - Motherboard Specifications; CPU and Chipset Support; Memory and Expansion; Graphics, Storage, and I;O

English
12
󰘰
CPU
Support
󰀲 4th Generation Intel
®
Core™ i7 / Core™ i5 / Core™ i3 /
Pentium
®
/ Celeron
®
processors for LGA 1150 socket
Chipset 󰀲 Intel
®
H81 Express Chipset
Memory
Support
󰀲 2x DDR3 memory slots supporting up to 16GB
󰀲 Supports DDR3 1600/ 1333/ 1066 MHz
󰀲 Dual channel memory architecture
󰀲 󰘯
Expansion
Slots
󰀲 1x PCIe 2.0 x16 slot
󰀲 2x PCIe 2.0 x1 slots
Onboard
Graphics
󰀲 1x VGA port, supporting a maximum resolution of 1920x1200
@ 60Hz, 24bpp
󰀲 1x HDMI port (H81M PRO-VH), supporting a maximum
resolution of 2560x1600@60Hz, 24bpp/ 1920x1080@60Hz,
36bpp
󰀲 1x DVI-D port (H81M PRO-VD), supporting a maximum
resolution of 1920x1200 @60Hz
Storage 󰀲 Intel H81 Express Chipset
- 2x SATA 6Gb/s ports (SATA1~2)
- 2x SATA 3Gb/s ports (SATA3~4)
- Supports Intel Smart Connect Technology
USB 󰀲 Intel H81 Express Chipset
- 2x USB 3.0 ports on the back panel
- 8x USB 2.0 ports (4 ports on the back panel, 4 ports
available through the internal USB connectors)
󰀲 VIA VL806 Chipset
- 2x Internal USB 3.0 connectors
Audio 󰀲 Realtek
®
ALC887 Codec
LAN 󰀲 Realtek
®
RTL8111G Gigabit LAN controller
Back Panel
Connectors
󰀲 1x PS/2 keyboard port
󰀲 1x PS/2 mouse port
󰀲 1x VGA port
󰀲 1x HDMI port (H81M PRO-VH)
󰀲 1x DVI-D port (H81M PRO-VD)
󰀲 4x USB 2.0 ports
󰀲 2x USB 3.0 ports
󰀲 1x LAN (RJ45) port
󰀲 3x audio jacks
