MSI MS-7846 - Front Panel Audio Connector; Clear CMOS Jumper

English
23
JAUD1: Front Panel Audio Connector
This connector allows you to connect the front audio panel located on your computer
case. This connector is compliant with the Intel
®
Front Panel I/O Connectivity Design
Guide.
1.MIC L
3.MIC R
10.Head
Phone Detection
5.Head Phone
R
7.SENSE_SEN
D
9.Head Phone
L
8.No Pin
6.MIC Detection
4.NC
2
.Ground
JBAT1: Clear CMOS Jumper
There is CMOS RAM onboard that is external powered from a battery located on the
󰘰
can automatically boot into the operating system (OS) every time it is turned on. If
󰘰
Keep Data Clear Data
1
1
Important
󰘯
Afterwards, open the jumper . Do not clear the CMOS RAM while the system is on
because it will damage the motherboard.
