Preface
viv
Safety Instructions
Read the safety instructions carefully and thoroughly�
All cautions and warnings on the device or user’s manual should be noted�
Refer servicing to quali󰘰ed personnel only.
Keep the User’s Guide that comes with the package for future reference�
To prevent 󰘰re or shock hazard, keep this device away from humidity and high
temperature�
Lay this device on a reliable 󰘱at surface before setting it up.
Make sure that the power voltage is within its safety range and has been
adjusted properly to the value of 100~240V before connecting the device to
the power outlet� Do not disable the protective earth pin from the plug� The
device must be connected to an earthed mains socket-outlet�
Always disconnect the power cord or switch the wall socket o󰘯 if the device
would be left unused for a certain time to achieve zero energy consumption.
The ventilator on the device is used for air convection and to prevent the device
from overheating� Do not cover the ventilator�
Do not leave the device in an unconditioned environment with a storage
temperature above 60
O
C or below -20
O
C, which may damage the device�
NOTE: The maximum operating temperature is around 40
O
C�
When cleaning the device, be sure to remove the power plug� Use a piece of soft
cloth rather than industrial chemical to clean the device� Never pour any liquid
into the opening; that could damage the device or cause electric shock�

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the MSI Optix MAG271C and is the answer not in the manual?

MSI Optix MAG271C Specifications

General IconGeneral
3DNo
Panel typeVA
Pixel pitch0.3114 x 0.3114 mm
Display surfaceMatt
Display diagonal27 \
Screen curvature1800 mm
Display technologyLED
Native aspect ratio16:9
Vertical scan range48 - 144 Hz
Screen curvature rating1800R
Viewable size, vertical336.312 mm
sRGB coverage (typical)115 %
Contrast ratio (dynamic)100000000:1
Contrast ratio (typical)3000:1
Display number of colors16.78 million colors
Viewable size, horizontal597.888 mm
Display brightness (typical)300 cd/m²
Supported graphics resolutions1920 x 1080 (HD 1080)
On/off switchYes
Product colorBlack
Market positioningGaming
HDMI version1.4
USB hub version2.0
USB upstream port typeUSB Type-B
VGA (D-Sub) ports quantity0
Tilt angle range-5 - 20 °
Cable lock slot typeKensington
Panel mounting interface100 x 100 mm
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)- W
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)225.2 mm
Width (with stand)612 mm
Height (with stand)451.8 mm
Weight (with stand)5600 g
