Getting Started
1-111-10
1
Power Button
2
Power Jack
3
DisplayPort
4
HDMI Port
5
USB-C Port
This port can send simultaneously video signal and power stream up to
PD 5V/3A� It doesn’t support data transmission function�
6
Headphone Jack
7
USB 2�0 Type A Port (MAG272C/ MAG272CR)
USB 3�2 Gen1 Type A Port (MAG272CQR)
8
USB 2�0 Type B Upstream Port (MAG272C/ MAG272CR)
USB 3�2 Gen1 Type B Upstream Port (MAG272CQR)
For USB Upstream Cable�
IMPORTANT
Check the package for USB Upstream
Cable and connect it to the PC and
monitor� Once this cable is connected, the
USB Type A Downstream Ports on the
monitor will be ready for use�
To Monitor
To PC
9
Navi Key
10
Kensington Lock
