PC2PC Bluetooth
Install and screw up the computer case.
3.
1
1
5
V
A
N
T
4.
Locate the antenna connector on the
transceiving module bracket at the
back panel of the computer case. Se-
cure the dipole antenna to this con-
nector and fix the antenna to a loca-
tion free from signal obstruction. Con-
crete walls, metal substances, paints
with metal composites,... etc. will cause
signal obstruction and disable the
Bluetooth function.
ANT
