MSI PRO B760-P WIFI User Manual

17
Continued from previous column
Internal USB
Connectors
∙ 1x USB 3.2 Gen 1 5Gbps Type-C front panel port (From
B760 chipset)
∙ 1x USB 3.2 Gen 1 5Gbps connector (From B760 chipset)
• Supports additional 2 USB 3.2 Gen 1 5Gbps ports
∙ 2x USB 2.0 connectors (From Hub-GL850G)
• Supports additional 4 USB 2.0 ports
Fan Connectors
∙ 1x 4-pin CPU fan connector
∙ 1x 4-pin water-pump fan connector
∙ 5x 4-pin system fan connectors
System Connectors
∙ 1x Front panel audio connector
∙ 2x System panel connectors
∙ 1x Chassis Intrusion connector
∙ 1x TPM module connector
∙ 1x Parallel port connector
∙ 1x Serial port connector
∙ 1x TBT connector (Supports RTD3)
Jumpers ∙ 1x Clear CMOS jumper
LED Features
∙ 4x EZ Debug LED
∙ 1x 4-pin RGB LED connector
∙ 2x 3-pin A-RAINBOW V2 (ARGB Gen2) LED connectors
Back Panel
Connectors
∙ 1x PS/2 port
∙ 4x USB 2.0 Type-A ports (From B760 chipset)
∙ 1x DisplayPort
∙ 1x HDMI™ port
∙ 1x 2.5G LAN (RJ45) jack
∙ 2x USB 3.2 Gen 2 10Gbps Type-A ports (From B760
chipset)
∙ 1x USB 3.2 Gen 2 10Gbps Type-C port (From B760 chipset)
∙ 2x Wi-Fi Antenna connectors
∙ 5x Audio jacks
∙ 1x Optical S/PDIF OUT connector
I/O Controller NUVOTON NCT6687 Controller Chip
Continued on next column

MSI PRO B760-P WIFI Specifications

General

Processor socket	LGA 1700
Processor manufacturer	Intel
Compatible processor series	Intel® Pentium® Gold
Maximum internal memory supported by processor	192 GB
Memory channels	Dual-channel
Number of memory slots	4
Supported memory types	DDR5-SDRAM
Supported memory clock speeds	6800, 6600, 6400, 6200, 6000, 5800, 5600, 5400, 5200, 5000, 4800 MHz
Supported memory clock speed (max)	6800 MHz
Ethernet LAN	Yes
LAN controller	Realtek RTL8111H
Wi-Fi standards	802.11a, 802.11ad, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.3
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Number of SATA III connectors	-
USB 3.2 Gen 1 (3.1 Gen 1) connectors	2
HDMI version	1.4
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA
Package depth	304.8 mm
Package width	243.84 mm
Cables included	SATA
BIOS type	UEFI AMI
ACPI version	6.4
BIOS memory size	256 Mbit
System Management BIOS (SMBIOS) version	3.5
Audio chip	Realtek ALC897
Cooling type	Passive
Component for	PC
Motherboard chipset	Intel B760
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10 x64, Windows 11 x64
