Specifications
CPU
 Supports 12th/ 13th Gen Intel® Core™ Processors,
Pentium® Gold and Celeron® Processors*
 Processor socket LGA1700
* Please go to www.msi.com to get the newest support status as new processors
are released.
Chipset Intel® B760 Chipset
Memory
 4x DDR5 memory slots, supporting up to 192GB*
 Supports 1R 5600 MHz (by JEDEC & POR)
 Max. overclocking frequency:
• 1DPC 1R Max speed up to 6800+ MHz
• 1DPC 2R Max speed up to 6400+ MHz
• 2DPC 1R Max speed up to 6000+ MHz
• 2DPC 2R Max speed up to 5600+ MHz
 Supports Intel® XMP 3.0 OC
 Supports Dual Controller Dual-Channel mode
 Supports non-ECC, un-buffered memory
* Please refer to www.msi.com for more information on compatible memory.
Expansion Slots
 1x PCIe x16 slot
• PCI_E1 slot (From CPU)
• Supports PCIe 4.0 x16
 2x PCIe x1 slots
• PCI_E2 & PCI_E3 slots (From B760 chipset)
• Support PCIe 4.0 x1
Onboard Graphics
 1x HDMI™ 1.4 port, supporting a maximum resolution of
4K 30Hz*/**
 1x DisplayPort 1.4 port, supporting a maximum resolution
of 4K 60Hz*/**
 1x VGA port, supporting a maximum resolution of
2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz*/**
* Available only on processors featuring integrated graphics.
** Graphics specifications may vary depending on the CPU installed.
SATA Ports
4x SATA 6Gb/s ports* (From B760 chipset)
* SATA5 will be unavailable when installing M.2 SATA SSD in the M2_2 slot.
Continued on next column
