Introductions

Bottom Side View

1. Ventilator

The ventilator is designed to cool the system. DO NOT block the ventilator for air

circulation.

2. Battery Reset Hole

Whenever the system firmware (EC) is upgraded or the system hangs, please 1)

power off the notebook; 2) remove the AC power; 3) use a straightened paperclip and

insert it to this hole for 10 secs; 4) connect the AC power; 5) power on the notebook.

3. SSD Slot (optional)

This notebook is equipped with a SSD M.2 slot that supports the SSD device with

PCIe interface. Contact the authorized dealer or service center for product service.

4. Stereo Speakers

This notebook may be equipped with built-in stereo speakers which deliver the high

quality sound, and supports the HD audio technology.
