Left Side View
1. Power Connector
This connector is to connect the AC/DC adapter and supply power for the notebook.
2. USB 3.2 Gen 2 Port (Type-C) (with DisplayPort function)
• USB 3.2 Gen 2, the SuperSpeed USB 10Gbps, delivers the higher interface
speeds for connecting various devices, such as storage devices, hard drives, or
video cameras, and offers more advantages over high-speed data transferring.
• The slim and sleek USB Type-C connector features reversible plug orientation.
• Optionally supports Power Delivery function with variable up to 100W power
input and maximum 5V/3A or 5V/1.5A power output when AC or DC power is
connected.
• Supports using a power bank to supply power to the notebook and charge the
battery pack. Make sure the charging power output of the power bank meets the
minimum requirements of the notebook.
3. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator for air
circulation.
4. HDMI™ Connector
HDMI™ (High-Definition Multimedia Interface) technology is the industry-leading
interface and de-facto standard connecting high-definition (HD) and ultra high-
definition (UHD) equipment.
5. Woofer Speaker
The woofer speaker is to reproduce low-pitched audio frequency.
