Introductions
Left Side View
1. Power Connector
This connector is to connect the AC/DC adapter and supply power for the notebook.
2. USB 3.2 Gen 2 Port
USB 3.2 Gen 2, the SuperSpeed USB, supports high-speed data transfer for
connected devices, such as storage devices, hard drives, or video cameras.
3. Status LED
Battery Status
• LED glows when the battery is being charged.
• LED turns amber while the battery is in low capacity status.
• Continuously blinking if the battery fails. If the problem
persists, please contact your local authorized retailer or
service center.
• Battery LED goes out when the battery is fully charged or
when the AC/DC adapter is disconnected.
4. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator for air
circulation.
5. HDMI™ Connector
HDMI™ (High-Definition Multimedia Interface) technology is the industry-leading
interface and de-facto standard connecting high-definition (HD) and ultra high-
definition (UHD) equipment.
To Next Page
