Introductions
1. Power Key/ Power LED/ Battery Reset
Power Key
• Press this key to turn the notebook power ON.
• While the notebook is turned on, quick press this key to
force the notebook into sleep state. Press again to wake up
the system from sleep state.
• Long press this key to force a shutdown, if needed.
Power LED
• Glowing white when the notebook power is turned on.
• LED goes off when the notebook goes to the sleep state.
Battery Reset
Whenever the system firmware (EC) is upgraded or the system
hangs, please 1) remove the AC power; 2) long press this key
for 20 secs and then the LED goes to blink, and after 5 more
secs the LED would go off; 3) connect the AC power; 4) power
on the notebook.
2. Built-In Spatial Array Microphone
The built-in microphone can be used for spatial voice recording with noise reduction or
high quality audio recording.
3. Fingerprint Sensor (optional)
This notebook may be equipped with a fingerprint sensor, allowing users to set up
their own fingerprints to unlock the notebook.
4. Touchpad
This is the pointing device of the notebook.
5. Keyboard
The built-in keyboard provides all the functions of a notebook keyboard. Refer to How
to Use the Keyboard for details.
6. Status LED
Caps Lock
Glows when the Caps Lock function is activated.
