Introductions
Left Side View
1. HDMI Connector
HDMI (High-Definition Multimedia Interface) technology is the industry-leading
interface and de-facto standard connecting high-definition (HD) and ultra high-
definition (UHD) equipment.
2. Battery Status
• LED glows when the battery is being charged.
• LED turns amber while the battery is in low capacity status.
• Continuously blinking if the battery fails. If the problem
persists, please contact your local authorized retailer or
service center.
• Battery LED goes out when the battery is fully charged or
when the AC/DC adapter is disconnected.
3. Power/ Thunderbolt (Type-C) combo ports
• Always plug the provided AC/DC adapter that comes with the package to either
port to supply power to the notebook and charge the battery pack.
• Thunderbolt™ 4 supports USB4, PCIe, HDMI, DisplayPort connection; 8K
display monitor output; up to 40Gbps transfer rate; Power Delivery function ; and
maximum 5V/3A portable charging power output when AC power is connected.
(Follow the Intel
®
Thunderbolt
TM
protocol specification).
• The notebook can be charged via this port with a power bank. Be noted that it is a
must to connect each port with a power bank and a separate cable.
• To connect devices to these ports, please connect one after another.
