2-15
Introductions
Left Side View
1. Kensington Lock
This notebook provides a Kensington Lock hole, which allows users to secure the notebook
in place with a key or some mechanical PIN device and attached through a rubberised
metal cable. The end of the cable has a small loop which allows the whole cable to be
looped around a permanent object, such as a heavy table or other similar equipment, thus
securing the notebook in place.
2. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator for air circulation.
3. Power Connector
To connect the AC/DC adapter and supply power for the notebook.
1. Kensington Lock
2. Ventilator
3. Power Connector
4. VGA Port
5. HDMI Port
6. Power Switch
4
5
1 32
6
