MSI V2 Series - USB; Audio; LAN; Back Panel Connectors

English
13
USB 󰀲 AMD A88X/ A78 Chipset
- 4x USB 3.0 ports (2 ports on the back panel, 2 ports
available through the internal USB connectors)
- 8x USB 2.0 ports (4 ports on the back panel, 4 ports
available through the internal USB connectors)
Audio 󰀲 Realtek
®
ALC887 Codec
LAN 󰀲 Realtek
®
RTL8111G Gigabit LAN controller
Back Panel
Connectors
󰀲 1x PS/2 keyboard port
󰀲 1x PS/2 mouse port
󰀲 4x USB 2.0 ports
󰀲 2x USB 3.0 ports
󰀲 1x VGA port
󰀲 1x DVI-D port
󰀲 1x HDMI port (A88XM-E35 V2/ A78M-E35 V2)
󰀲 1x LAN (RJ45) port
󰀲 3x audio jacks
Internal
Connectors
󰀲 1x 24-pin ATX main power connector
󰀲 1x 4-pin ATX 12V power connector
󰀲 6x SATA 6Gb/s connectors (A88XM-E35 V2/ A78M-E35 V2)
󰀲 4x SATA 6Gb/s connectors (A88XM-P33 V2)
󰀲 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
󰀲 1x USB 3.0 connector (supports additional 2 USB 3.0 ports)
󰀲 1x 4-pin CPU fan connector
󰀲 1x 4-pin system fan connector
󰀲 1x 3-pin system fan connector
󰀲 1x Front panel audio connector
󰀲 2x System panel connectors
󰀲 1x Chassis Intrusion connector
󰀲 1x TPM module connector
󰀲 1x Serial port connector
󰀲 1x Parallel port connector (A88XM-E35 V2/ A78M-E35 V2)
󰀲 1x Clear CMOS jumper
󰀲 2x USB power jumpers
