Introductions
2-6 2-7
Right Side View
1. Audio Ports
Microphone
Used for an external microphone.
Headphone
A port for speakers or headphones.
2. USB 3.2 Gen 1 Port (Type-C)
USB 3.2 Gen 1, the SuperSpeed USB, delivers the higher interface speeds for
connecting various devices, such as storage devices, hard drives, or video cameras,
and offers more advantages over high-speed data transferring.
The slim and sleek USB Type-C connector features reversible plug orientation and
cable direction and supports 5V/3A portable charging power when AC power is
connected. However, the maximum portable charging power limitation may up to
5V/1.5A while battery DC power is connected.
3. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator for air
circulation.
