MSI Z270 KRAIT GAMING - Page 27

27
Overview of Components
Component Contents
Port Name Port Type Page
CPU_FAN1,SYS_FAN1~4, PUMP_
FAN1
Fan Connectors 37
CPU_PWR1, ATX_PWR1 Power Connectors 35
CPU Socket LGA1151 CPU Socket 28
DIMMA1, A2, B1, B2 DIMM Slots 29
JAUD1 Front Audio Connector 38
JBAT1 Clear CMOS (Reset BIOS) Jumper 39
JCI1 Chassis Intrusion Connector 38
JCOM1 Serial Port Connector 35
JFP1, JFP2 Front Panel Connectors 34
JLED1 RGB LED connector 40
JLPT1 Parallel Port Connector 40
JTPM1 TPM Module Connector 39
JUSB1~2 USB 2.0 Connectors 36
JUSB3~4 USB 3.1 Gen1 Connectors 36
M2_1~2 M.2 Slots (Key M) 32
PCI_E1~6 PCIe Expansion Slots 30
SATA1~6 SATA 6Gb/s Connectors 33
