MSI Z77A-G45 Thunderbolt series User Manual


Preface
Copyrght Notce
The materal n ths document s the ntellectual property of MICRO-STAR INTERNA-
TIONAL. We take every care n the preparaton of ths document, but no guarantee s
gven as to the correctness of ts contents. Our products are under contnual mprove-
ment and we reserve the rght to make changes wthout notce.
Trademarks
All trademarks n ths manual are propertes of ther respectve owners.
MSI
®
s regstered trademark of Mcro-Star Int’l Co.,Ltd.
NVIDIA
®
s regstered trademark of NVIDIA Corporaton.
ATI
®
s regstered trademark of AMD Corporaton.
AMD
®
s regstered trademarks of AMD Corporaton.
Intel
®
s regstered trademarks of Intel Corporaton.
Wndows
®
s regstered trademarks of Mcrosoft Corporaton.
AMI
®
s regstered trademark of Amercan Megatrends Inc.
Award
®
s a regstered trademark of Phoenx Technologes Ltd.
Sound Blaster
®
s regstered trademark of Creatve Technology Ltd.
Realtek
®
s regstered trademark of Realtek Semconductor Corporaton.
JMcron
®
s regstered trademark of JMcron Technology Corporaton.
Netware
®
s regstered trademark of Novell, Inc.
Lucd
®
s trademark of LucdLogx Technologes, Ltd.
VIA
®
s regstered trademark of VIA Technologes, Inc.
ASMeda
®
s regstered trademark of ASMeda Technology Inc.
Pad, Phone, and Pod are trademarks of Apple Inc.
Revson Hstory
Revson Revson Hstory Date
V2.0 Frst release 2012/08
￭
￭
￭
￭
￭
￭
￭
￭
￭
￭
￭
￭
￭
￭
￭
￭

MSI Z77A-G45 Thunderbolt series Specifications

General

Chipset	Intel Z77
Socket	LGA 1155
Memory Support	DDR3
Max Memory	32GB
Memory Slots	4
PCI Express x16	2
PCI Express x1	2
Audio	Realtek ALC892
Form Factor	ATX
RAID Support	RAID 0, 1, 5, 10
USB 2.0 Ports	8
LAN	Realtek 8111E
Thunderbolt	1
SATA Ports	2 x SATA III 6Gb/s, 4 x SATA II 3Gb/s
USB 3.0 Ports	4 (2 rear, 2 via header)
