MSI Z790 PROJECT ZERO - Page 32

32
3. Remove or exchange the screws according to your SSD length. Skip this step if you
install 2280 SSD.
33
33
22110
2260
2242
4. Insert your M.2 SSD into the M.2 slot at a 30-degree angle.
5. Rotate the EZ M.2 Clip to fix the M.2 SSD.
30º30º
30º30º
55
55
44 44
22110 SSD
2242/60/80 SSD
