MST FXX-D S User Manual

17
FXX-D S
避震架
DAMPER STAY
PARTS BAG
14
STEP 2
Attaching rear damper stay
STEP 1
Attaching front damper stay
安裝前避震架
安裝後避震架
Front damper stay
×
1
前避震架
Rear damper stay
×
1
後避震架
4
.
8
Copper hex ball
×
4
4
.
8
銅製外六角球頭
3
×
5
.
5
×
2
spacer
×
2
墊片
M
3
×
8
screw
×
4
圓頭螺絲
M
3
×
10
screw
×
2
止付螺絲
M
3
×
8
screw
×
2
止付螺絲
3
×
8
screw
×
4
自攻螺絲
OPTIONAL PARTS
210386
FXX Carbon front damper stay
3
.
5
FXX
碳纖維前避震架
3
.
5
210387
FXX Carbon rear damper stay
3
.
5
FXX
碳纖維後避震架
3
.
5
3.5mm
5.5mm
3
4
.
8
copper hex ball
4
4
.
8
copper hex ball
2
M
3
×
8
2
3
×
8
2
M
3
×
10
2
M
3
×
8
3
3
×
5
.
5
×
2
spacer
1
1
front damper stay
1
rear damper stay
1
STEP 1
避震器
DAMPER
PARTS BAG
15
Coil spring
29
mm
×
2
(
silver
)
避震彈簧
29
mm
(
銀
)
Soft coil spring
29
mm
×
2
(
red
)
軟避震彈簧
29
mm
(
紅
)
Damper cylinder
×
4
避震筒身
Piston rod
×
4
避震軸心
Piston
×
4
避震活塞
Cylinder cap
×
4
避震器上蓋
Rod guide cap
×
4
避震器下蓋
Damper adjuster
×
4
避震器拉桿
Damper retainer
×
4
避震器彈簧座
10
.
8
×
0
.
9
O
-
ring
×
4
O
環
M
3
×
5
screw
×
4
沉頭螺絲
Oil seal
×
4
避震器氣室
Damper O
-
ring P
3
×
4
避震器
O
環
Rod guide
×
4
避震器下蓋墊片
E
-
clip
×
10
E
形扣
Damper assembly
oil seal
1
2
cylinder cap
1
shock spring
2
damper retainer
12.5mm
1
piston rod
3
piston
2
4
E
-
clip
1
damper cylinder
10
.
8
×
0
.
9
o
-
ring
2
4
rod guide
3
damper O
-
ring
5
rod guide cap
damper adjuster
Slowly
Make 4
X4
Make 4
X4
避震器組裝
OIL
拉下活塞並填入矽油，緩慢上下移動活塞將氣泡移除。
Pull down piston and pour oil into cylinder.
Remove air bubbles by slowly moving
piston up and down.
將軸心下拉
4
mm
後，蓋上氣室並以面紙拭去溢出的矽油。
Pull down piston rod
4
mm, attach oil seal and
absorb oil overflow with tissue paper.
前面裝配銀色
後面裝配紅色
Front
-
Silver
Rear
-
Red
4mm
OIL
OIL
