No.
Part name
Quantity
1
Square support
1
2
Mounting hole for the connection
1
3
Phillips screw
2
4
Connection to extraction system
1
5
Triangular knob
2
6
Aluminum track
4
7
Hexagonal head screw
2
8
Self-tapping screw with flat head
20
9
Square
2
10
Cutter guard
1
11
Hexagonal head screw
6
12
Knob
6
13
Measuring cup
2
14
Flat washer
2
