IDENTIFICATION OF CONTROLS
Main unit
1. Setup
2.
Up / Previous
3. Down / Next
4. Enter
5. /Vol-
6. /Vol+
7. Source
8. On/Off
9. USB
10. Earphone socket
11. AV out
12. DC out
13. DC In 9-12V
14. Mute
15. Up
16. Down
17. /Vol-
18. /Vol+
19. Mode
20. Back light
21. DC In 9-12V
22. AV in
23. Earphone Socket
24. On/Off
Instruction Manual
SETUP ENTE R
SOURC E
\
\
VOL+ \
VOL +\
1
14 15 16 19 17 18 20
8
21
22
23
24
9
10
11
12
13
42 53 6 7
