E-504
3.0 LEISTUNGSDATEN
Die allgemeinen Leistungsdaten sind dem jeweiligen
Propellerkennblatt zu entnehmen. Für den Betrieb gelten die
Angaben im Propellerlogbuch.
Flanschformen:
A = Motorseglertriebw., TK=80mm, 7/16"-20UNF
B = SAE Nr. 2 mod. Bolzen 1/2"-20UNF
C = SAE Nr. 2 mod. Bolzen 7/16"-20 UNF
D = ARP 502 Bolzen 1/2"-20 UNF
E = ARP 880 Bolzen 9/16"-18 UNF
F = SAE No. 1 Bolzen 3/8 "- 24 UNF
K = M 14 P/PF Bolzen 9/16”-18 UNF
N = PT6A-67A Bolzen 9/16” - 18 UNF
P = Rotax 912/14 Bolzen 1/2" - 20 UNF
R = Austrodiesel Bolzen 1/2" - 20 UNF
Regler: P-480-( ) nach Spezifikation für die jeweilige Trieb-
werks/Flugzeug-Kombination.
Seite 11 08.10.2008
3.0 PERFORMANCE DATA
For the general performance data refer to the applicable propeller
TCDS. For operation refer to your Propeller-Logbook.
Type of Flanges:
A = Motorglider engines, bolt dia. 80 mm, bolts 7/16" - 20 UNF
B = SAE No. 2 mod. bolts 1/2" - 20UNF
C = SAE No. 2 mod. bolts 7/16" - 20 UNF
D = ARP 502 bolts 1/2" - 20 UNF
E = ARP 880 bolts 9/16 "- 18 UNF
F = SAE No. 1 bolts 3/8 "- 24 UNF
K = M 14 P/PF bolts 9/16”-18 UNF
N = PT6A-67A bolts 9/16” - 18 UNF
P = Rotax 912/14 bolts 1/2" - 20 UNF
R = Austrodiesel bolts 1/2" - 20 UNF
Governor: P-480-( ) according to the specification for the
applicable engine/aircraft combination.
Page 11 2008/10/08
