E-504
5.6 Je nach Spinnerkonstruktion entweder die Grundplatte auf die Kur-
belwelle stecken oder an der Nabe befestigen.
5.7 Propeller vorsichtig auf die Kurbelwelle schieben, dabei auf die Po-
sition der Spinnerplatte mit den Blattausschnitten achten. Falls aus
konstruktiven Gründen die Flanschbolzen gleichzeitig mit einge-
dreht werden müssen, ist darauf zu achten, dder Propeller nicht
mit den Bolzen aufgezogen wird, sondern lose nachgeschoben,
um eine Beschädigung des Führungsbunds des Propellers zu
vermeiden, die durch Scherspäne zu Undichtheit am O-Ring
führen können.
Achtung:
Niemals den Propeller mit den Flanschbolzen auf den
Triebwerkflansch ziehen, sondern lediglich nur mit der Hand
aufschieben.
5.8 Flanschbolzen oder Stopmuttern mit Unterlegscheiben gleichmäßig
und über Kreuz anziehen. Flanschbolzen paarweise mit 0,8 mm
Edelstahldraht sichern.
Anzugsmomente:
7/16" 20 UNF Stopmuttern 45 - 47 Nm
1/2“ 20 UNF Stopmuttern (< 300 PS) 85 - 90 Nm
1/2" 20 UNF Bolzen (< 300 PS) 85 - 90 Nm
1/2" 20 UNF Stopmuttern (< 300 PS) 110 - 115 Nm
1/2" 20 UNF Bolzen (> 300 PS) 120 - 135 Nm
9/16" 18 UNF Stopmuttern ungefettet 135 - 150 Nm
9/16" 18 UNF Stopmuttern gefettet 92 - 97 Nm
Achtung:
Wenn nicht anders beschrieben, gelten die Werte für ein
ungeschmiertes, leichtgängiges Gewinde.
Anzugsmomente sorgfältig überprüfen, um Beschädigungen
der Schrauben zu vermeiden!
Seite 18-2 18.10.2019
5.6 Depending on spinner design, install backplate on crankshaft or on
propeller hub.
5.7 Install the propeller carefully to the crankshaft. Observe the
position of the spinner backplate for the blade position. If the
design does not permit installing the flange bolts after the propeller
has been fixed on the crankshaft, please observe that the propeller
should not be pulled onto the crankshaft with the bolts in order to
avoid damage to the hub and to avoid shearing off material
causing oil leaks on the o-ring.
Attention:
Never pull a propeller onto the engine flange by the bolts, only
install by hand.
5.8 Mounting bolts or stop nuts with washers should be tightened
crosswise with equal force. Safety wire flange bolts in pairs with
.032" stainless steel wire.
Torque:
7/16" 20 UNF stopnuts 34 - 35 ftlb
1/2“ 20 UNF stopnuts (< 300 HP) 63 - 66 ftlb
1/2" 20 UNF bolts (< 300 HP) 63 - 66 ftlb
1/2" 20 UNF stopnuts (< 300 HP) 80 - 85 ftlb
1/2" 20 UNF bolts (> 300 HP) 90 - 100 ftlb
9/16" 18 UNF stopnuts ungreased 100 - 110 ftlb
9/16" 18 UNF stopnuts greased 68 - 71.5 ftlb
Note:
Torque values are valid for dry, free-moving threads only.
Carefully check the torque to avoid overtorque of the bolts!
Page 18-2 2019-10-18
