MTD 02B User Manual

25
Ref
No.
Part Number Description
1. 747-1161A Blade Control
2. 749-1092A Upper Handle
3. 746-04299 Control Cable
4. 726-0240 Cable Tie
5. 664-04007A Grass Bag
6. 747-04080A Grass Bag Frame
7. 720-0279 Handle Knob
8. 731-05642 Trailshield
9. 747-04588 Pivot Rod
10. 731-05865 Rear Discharge Door
11. 687-02280A Rear Handle Bracket Assy. - LH
687-02279A Rear Handle Bracket Assy. - RH
12. 787-01279 Deck 21-inch
13. 687-02075B Front Hgt. Adj. Assy., 8” Whl. - LH
687-02074B Front Hgt. Adj. Assy., 8” Whl. - RH
14. 782-5002B Front Baffle
15. 748-0377C Blade Adapter w/Star
16. 742-0741 21-inch Mulching Blade
17. 736-0524B Bell Blade Support
18. 710-1257 Hex Screw, 3/8-24 x 2.5
19. 731-04177 Side Discharge Chute
20. 17032A Deflector Chute Adaptor
21. 732-1014 Torsion Spring
22. 747-0710 Hinge Pin
23. 687-02055 Mulch Plug Assembly
24. 712-04065 Flange Lock Nut 3/8-16
25. 787-01290 Height Adjustment Plate
26. 687-02337 Pivot Arm Assy RH (8” wheel)
687-02338 Pivot Arm Assy LH (8” wheel)
27. 734-1987 Front Wheel, 8 x 1.8, Bar
28. 738-0507B Shoulder Scr., .5D x .434 - LH Rear
Ref
No.
Part Number Description
738-04266 Shoulder Scr., .5D x .385 - RH Rear
29. 732-0404 Front Spring Lever
30. 720-0426 Height Adjust Knob
31. 710-0599 TT Screw, 1/4-20 x .500
32. 736-0270 Bell Washer
33. 710-0654A TT Screw, 3/8-16 x 1.0
34. 710-0216 Hex Screw, 3/8-16 x .75
35. 710-1652 TT Screw, 1/4-20 x .625
36. 720-0312 Foam Grip
37. 734-04082 Rear Wheel, 12 x 1.8, Bar
38. 710-1205 Eye Bolt
39. 732-0866 Rear Hi-Wheel Spring Lever
40. 687-02335 Rear Pivot Arm Assy - RH
687-02040A Rear Pivot Arm Assy - LH
41. 714-0104 Hairpin Clip
42. 720-04072 Star Knob
43. 710-0703 Carriage Bolt ,1/4-20 x .75
44. 731-04150C Rear Baffle
45. 710-1241 Screw HL, 1/4-15 x 1.00
46. 732-04090A Torsion Spring - RH
47. 710-1174 Carriage Bolt, 5/16-18 x 2
48. 712-0397 Wing Nut
49. 749-0928A Lower Handle
50. 712-04064 Nut, Flange Lock, 1/4-20
51. 732-04089A Torsion Spring - LH
52. 738-04266 Shoulder Screw, .5 D x .385 - Front
53. 710-0606 Screw, 1/4-20 x 1.50
54. 746-04239A Choke Cable
55. 710-04577 Screw, Machine, M4-.7
56. 731-05400 Engine Shroud
Model 54M
† If Equipped

MTD 02B Specifications

General

Brand	MTD
Model	02B
Category	Lawn Mower
Language	English
