17
Model Series 410
Ref.
No.
Part No. Part Description
1. 710-1017 Hex Screw 1/4-20 x.625
2. 786-0168 Shift Cover - Tecumseh
3. 686-0095 Crank Shift Assembly
4. 712-04063 Hex Lock Nut 5/16-18
5. 715-0120 Spiral Pin
6. 786-0117 Shift Cover Mounting Bracket
7. 710-3008 Hex Cap Screw 5/16-18 x.75
8. 712-3010 Hex Nut 5/16-18
9. 736-0242 Bell Washer.340 ID x.872 OD
10. 710-3180 Hex Cap Screw 5/16-18 x 1.75
11. 710-1007 Hex Washer Screw 3/8-16 x 1.5
12. 619-0009A Frame Counterweight
13. 642-0015 Tine Assembly - LH
642-0016 Tine Assembly - RH
14. 711-0415 Clevis Pin
15. 714-0149B Cotter Pin
16. 634-04233 Complete Wheel Ass’y - RH (14”)
17. 710-0606 Hex Head Screw 1/4-20
18 734-1796 Tire Only (14”)
634-04218 Rim Only (6.0 x 3.25)
19. 712-04064 Flange Lock Nut 1/4-20
21. 710-1090 Flange Screw 5/16-18 x 1.25
22. 686-0031A Belt Keeper Bracket Ass’y
23. 736-0119 Lock Washer 5/16
24. 710-0237 Hex Cap Screw 5/16-24 x.625
25. 756-0971 Inner Pulley Half
26. 756-0972 Outer Pulley Half
27. 754-0438 V-Belt
28. 756-0405 Flat Idler
29. 738-0899 Bolt 5/16-18 x 1/4-28 x 2.35
30. 736-0256 Flat Washer.635 ID x.930 OD
31. 756-0634 Flat Pulley
32. 736-0105 Spring Washer.401 ID x.870 OD
33. 712-0379 Flange Lock Nut 3/8-24
34. 736-0452 Bell Washer.396 ID x 1.140 OD
35. 710-0152 Hex Cap Screw 3/8-24 x 1.0
36. 786-0080 Idler Bracket
37. 710-0723 Hex Cap Screw 3/8-16 x 1.25
38. 738-0876 Shoulder Nut 7/16-20
39. 736-3020 Flat Washer.271 ID x.630 OD
40. 786-0100 Belt Cover
41. 712-0392 Hex Lock Nut 1/4
42. 786-0107 Cable Bracket
Ref.
No.
Part No. Part Description
IMPORTANT: For a proper working machine, use Factory
Approved Parts.
V-BELTS are specially designed to engage and disengage
safely. A substitute (non OEM) V-Belt can be dangerous by not
disengaging completely.
