9
Choke Lever
(If Equipped)
The choke lever is located on top of the carburetor on
the back of the engine underneath the muffler. It is used
to enrich the fuel mixture in the carburetor when starting
a cold engine.
Be careful when disengaging the Choke,
especially after the engine warms up, the
muffler will be hot!
Primer Button
(If Equipped)
The primer button is located behind the air cleaner. It is
used to enrich the fuel mixture in the carburetor when
starting a cold engine.
Depth Stake
The depth stake controls the tilling depth. Refer to
‘‘Setting the Depth’’ in the Operating Section.
Handle Adjustment Crank
The handle may be adjusted to the height desired.
Loosen the handle height adjustment lock a few turns.
Pivot handle up or down to desired position. Tighten
lock. See Figure 8.
Fuel Shut-Off Valve
(If Equipped)
Make sure the valve is in the On (horizontal) position
when starting the unit. Any time the tiller is not in
operation (i.e., storing, performing maintenance or
adjustment), make sure the valve is in the OFF
(vertical) position.
Engine Controls
See the separate engine manual for additional
information and functions of the engine controls.
