MTD 420 - Page 19

Models 410 thru 429
REF.
NO,
1
2
3
4
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
3O
31
PART NO.
747-0824
647-0004
747-0615
710-1205
720-0279
710-1174
720-0276
710-0605
710-1270
736-0501
712-0324
746-0876
749-0538C
749-0920A
720-0295
749-0928
726-0240
764-0310
746-0550
746-0737
746-0552
746-0553
746-0842
746-0847
746-0843
764-0311
764-0309
764-0476A
714.-0104
732-0678
732-0677
782-7000
751B213146
7510007775
646-0875
811-00185
746-0883
710-1237
735-0639
732-0700
731-1236
DESCRIPTION
Control Handle (Std.)
Control Handle Ass'y. (Deluxe)
Control Handle
(11A-428-02?J722)
Rope Guide
Handle Knob 1/4-20 Thd.
Curved Hd. Bolt 5/16-18 x 2" Lg
Hand Knob
Oval C-Sunk Mash. Scr.
Oval C-Sunk Mash. Scr. (Model
411 Only)
Spr. Wash, .66" I.D.
Hex L-Nut 1/4-20 Thd.
Throttle Lever
Upper Handle
Upper Handle (11A--428-022J722)
Foam Grip (Optional)
Lower Handle
Cable Tie
Rear Catcher Frame
Control Cable-39" (410, 412, 414,
424)
Control Cable-51" (411,413, 425)
Control Cable-49" (411)
Control Cable-36" (416, 418, 428,
429)
Throttle Control Wie - 51"
(410,412, 414, 424)
Throttle Control Wire - 42" (413,
425)
Throttle Control Wire - 55" (416,
418, 428, 429)
Front Catcher Frame
Grass Bag
Grass Bag w/Logo
Int. Cotter Pin 5/16" Die.
Door Spdng - R.H.
Door Spring - LH.
Rear Discharge Door
Cable Clamp (B&S)
Casing Clamp (Tec.)
Throttle Body
Throttle Box Comp. (Incl. Ref. 7, 8,
9, 10,25)
Housing, E.R.S. w/o Throttle
(11 A411A022J722)
Engine
Hex Wash. Hd. Scr. #10-32 x .62"
Lg. (B&S)
Spark Plug Boot (Optional)
Wire Rod
Rear Flap
REF.
NO, PART NO.
32 753-0588
33 710-1044
34 736-0524A
36 742-0741
742-0641
39 736-0356
40 712-0798
41 15261A
42 15262B
43 14832
44 738-0507B
45 736-0105
46 738-0102
47 720-0190
48 732-0417A
49 14578
14579
50 14765
14766
51 782-5002
52 710-0654A
53 782-5003
54 710-1017
55 710-0896
56 682-0516
57 682-0515
58 782-0310A
59 (See Chart)
60 731-0981 A
720-0249
61 764-0433
62 731-1322A
731-1878
63 710-0286
64 712-0324
65 782-9011
66 782-5007A
67 782-5004
68 731-1405
69 711-0996
70 726-0201
71 710-0192
72 720-0275
73 731-1506
74 738-0213
738-0102
75 750-0535
76 736-0504
DESCRIPTION
Blade Adapter Kit
(Incl. Ref. 33 & 34)
Hex Bolt 3/8-24 x 1.5" Lg.
Blade Bell Support
21" Mulching Blade -1 Bolt Mount
21" Blade - 1 Bolt Mount
Bell-Wash..39" I.D. x 1.38"
Hex Nut 3/8-16 Thd.
Height Adj. Plate
Pivot Bar
Spring Lever Ass'y. w/Knob
Shld. Bolt .5" Die. x .357"
Bell-Wash..38" I.D, x .88" O.D.
Axle Bolt
Spdng Lever Knob
Spring Lever
Height Adj. Ass'y. Comp. - R.H.
Height Adj. Ass'y. Comp. -L.H. (Not
Shown)
Pivot Bar R.H.
Pivot Bar L.H. (Not III.)
Front Baffle
Hex L-Wash. Hd. Scr. 3/6-16 x 1"
Lg.
Rear Baffle
Torx Mech. AB-Tap Scr. 1/4 x 62"
Lg.
Hex Ind-Wash.Scr. 1/4 -14 x .625
Lg.
Handle Brkt. Ass'y. - R.H.
Handle Brkt. Ass'y. - L.H.
21" R.D. Deck
Wheel Assy. Comp.
Hub Cap - Gray, Red. Spoke
Hub Cap - Gray, Euro
Grass Bag
Hard Top Cover
Hard Top Cover w!Logo (Opt.)
Pan Hd. Mash. Scr. 1/4-20 x .5" Lg.
Hex Nylon L-Nut 1/4-20 Thd.
Mounting Bracket
Mulching Baffle Plug (Optional)
Mulching Baffle - R.R. (Optional)
Deflector (Optional)
Rod (Optional)
Push Speed Nut (Optional)
Truss Scr. #10-24 x .38" Lg.
Knob
Deck Shroud (Optional)
Rear Axle Bolt 1"
Axle Bolt
Spacer 1"
Wave Washer 1"
1"Used on units with ball bearing rear wheels.
