MTD 601 - Page 37

Model601
REF.
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
17
19
2O
21
22
23
24
25
26
27
28
29
i
PART
NO.
732-0614
716-0231
736-0336*
736-0337*
736-0349*
736-0335
710-1325
719-04017
711-1109
741-0335
717-1464
716-0108
741-0340
721-0338
618-04041
741-0336
717-04056
718-04045
711-04134
736-0495*
736-0494*
741-0337
611-0011
741-0862
732-0863
719-04018
717-0678
761-0202
710-1206
661-0001
737-0148
DESCRIPTION
Ring, Wire
Ring, E Type,.750
Flat Washer, 5/8 x 1.0 x.030
Flat Washer, 5/8 x 1.0 x.040
Flat Washer, 5/8 x 1.0 x.020
Washer, Thrust.635 x 1.26 x.06
Self-tapping Screw, 1/4-20 x 1.625
Upper Housing
Input Shaft
Needle Bearing,.625 x.813 x.495
14-tooth Bevel Pinion
Retaining Ring,.437
Sleeve Bearing,.75 x.1.0 x 1.0
Seal,.75 x 1.0 x.125
Differential Assembly
Flange Bearing, 5/8 x 3/4 x 3/4
42-tooth Bevel Gear
Clutch Collar
Drive Shaft
Thrust Washer, 1.0 x.632 x.0
Flat Washer,.632 x 1.00 x.035
Flange Bearing, 5/8 x 3/4 x 15/16
Detent Shaft Assembly
Detent Ball
Compression Spring
Lower Housing
Brake Puck
Brake Disc
Self-tapping Screw, 1/4-20 x 2.375
Brake Assembly
Grease (19 oz.)
*Use applicable washers (ref. no.'s 3 or 20) in this application allowing.0150/.O020 in. end-play.
NOTE: If rebuilding the upper housing, include two ounces (2 oz.) of Unirex ® N3 grease (Part No. 737-0289) in the input shaft cavity.
