MTD 608 - Page 31

31
Ref.
No.
Part
No.
Description
1 747-1130B Deck Stabilizer Rod
2 683-0197B Lift Shaft Assembly
3 711-0332 Clevis Pin, .5 x .78
4 712-0206 Hex Nut, 1/2-13
5 712-0431 Flange Lock Nut, 3/8-16
6 712-0429 Flange Lock Nut, 5/16-18
7 712-3083 Hex Nut, 1/2-13
8 714-0104 Internal Cotter Pin
9 714-0145 Internal Cotter Pin
10 716-0106 E-Ring
11 720-0311 Handle Grip
12 732-0874 Torsion Spring
13 732-1184 Extension Spring, .84 x 4.6
14 736-0275 Flat Washer, 5/16
15 736-0921 Lock Washer, 1/2
16 736-3019 Flat Washer, .531 x 1.062 x .134
17 736-3084 Flat Washer, .51 x 1.12 x .06
18 738-0138A Hex Cap Screw, 5/16-18 x .62
19 738-0143 Shoulder Screw, 3/8-16
20 741-0225 Hex Flange Bearing
21 741-0715 Snap Flange Bearing
22 746-0968 Lift Cable, 16.16
746-1144 Lift Cable, 15.62
23 747-1111A Lift Handle
24 756-1154 Roller Pulley
25 783-0678A Lift Arm
26 783-0720A Deck Stabilizer Bracket
27 710-0260A Carriage Bolt, 5/16 x .62
28 710-0604A Self-tapping Screw, 5/16-18 x .625
29 736-0331 Bell Washer, .390 x 1.13 x .062
30 720-04009 Knob, 3/8-16
31 738-04012 Shoulder Screw
32 736-3078 Flat Washer, .349 x 1.0 x .063
33 783-1010A Lift Adjustment Bracket
34 783-04314 Fender (Models w/Cup Holder)
783-04333 Fender (Models w/o Cup Holder)
35 783-1489 Seat Mounting Bracket
36 738-0296 Shoulder Screw
37 726-0201 Speed Clip
38 783-0209A Seat Lift Bracket
39 757-04001 Seat: Low Back
757-04002A Seat: Medium Back
757-04003 Seat: High Back
40 735-0672 Foot Pad RH, Rubber
723-0484 Foot Pad RH, Grit
41 735-0673 Foot Pad LH, Rubber
735-0483 Foot Pad LH, Grit
42 726-3046 Foot Pad Clips
43 714-0111 Cotter Pin
44 783-04081 Seat Pivot Bracket
45 736-0204 Flat Washer, .344 x .62
46 731-0511 Trim Strip
47 731-1990 Lift Lever Cover
48 731-2104B Shift Lever Cover w/ Cup Holder
49 710-0895 Self-Tapping Screw, 1/4-15 x .75
50 731-04591 Cup Holder
51 710-0599 TT Screw, 1/4-20 x 0.5
52 731-04074 Spacer: Seat Adjustment
53 738-0137A Shoulder Screw 1/4-20
54 783-0738A Seat Bracket
55 736-3019 Flat Washer
56 732-0499 Compression Spring
57 738-0966 Shoulder Screw 3/8-16
58 720-0309A Grip: Seat Adjustment
59 712-0324 Lock Nut 1/4-20
60 783-0611 Seat Stop
61 710-1268 B Screw #10-16 x 0.375
62 783-0739 Seat Lever
63 736-0275 Flat Washer
64 783-0753 Seat Adjustment Selector
65 738-0966 Shoulder Screw 3/8-16
66 710-0870 Hex Washer Hd. Screw
Ref.
No.
Part
No.
Description
Models 607 & 608
