MTD 608 - Page 35

35
Ref.
No.
Part
No. Description
1 17840 Mounting Bracket
2 618-04133 Drive Assembly
3 618-04147 Variable Spd. Pulley Assembly
4 647-04020 Shift Lever Assembly
5 710-0607 TT Screw 5/16-18 x 0.5
6 710-0726 AB Screw 5/16-12 x 0.75
7 710-0809 TT Screw 1/4-20 x 1.25
8 710-1007 TT Sems Screw 3/8-16 x 1.5
9 710-1266 Hex Bolt 5/16-18 x 3.5
10 710-3144 Hex Bolt 3/8-16 x 2.0
11 711-0736 Ferrule
12 712-0241 Hex Nut 3/8-24
13 712-0429 Hex Lock Nut 5/16-18
14 712-0431 Flange Lock Nut 3/8-16
15 714-0104 Hairpin Clip
16 714-0111 Cotter Pin
17 714-0209 Hairpin Clip
18 714-0470 Cotter Pin
19 720-04028 Shift Knob
20 723-3018 Ball Joint
21 732-0384 Extension Spring
22 732-0525 Spring Clip
23 732-0716 Extension Spring
24 732-0963 Extension Spring
25 736-0169 Lock Washer 3/8
26 737-3007 Grease
27 738-0372B Shoulder Spacer
28 747-04146 Shift Rod
29 747-04164 Brake Rod
30 747-1127 Idler Adj. Rod
31 748-0334 Spacer: Transaxle
32 750-0566A Spacer
33 754-0467 V Belt
34 754-0468 V Belt
35 756-0981A Flat Idler Pulley
36 783-04283 Shift Bracket
37 783-04360 Shift Bracket
38 783-04442 Double Idler Bracket: Center
39 647-0031C Brake Control Assembly
40 647-0032A Speed Control Assembly
41 683-0266 Drive Pedal Assembly
42 710-0650 TT Screw 5/16-18 x 0.875
43 710-0726 AB Screw 5/16-12 x 0.75
44 710-1260A LD Screw 5/16-18 x 0.75
45 710-1611B TT Screw 5/16-18 x 0.75
46 711-04159 Pin
47 712-0130 Hex Lock Nut 3/8-16
48 712-3004A Flange Lock Nut
49 714-0104 Cotter Pin
50 726-04028 Push Nut
51 732-0335 Compression Spring
52 732-0955 Extension Spring (Models w/ cruise)
53 732-0963 Extension Spring
54 735-0662 Control Pad
55 735-3049 Brake Pad
56 736-0262 Flat Washer
57 736-3008 Flat Washer
58 738-0155 Shoulder Screw
59 738-0380 Shoulder Screw (Models w/ cruise)
60 741-0225 Hex Flange Bearing
61 741-3065B Hex Flange Bearing: Split
62 747-04093 Brake Lock Rod
63 747-04096 Cruise Control Rod (Models w/ cruise)
64 748-04039 Cruise Latch (Models w/ cruise)
65 783-0653F Steering Support Bracket
66 783-0732 Lock-Out Bracket
67 783-0773A Brake Pedal
68 783-0780B Neutral Return Bracket
69 756-04002 Transmission Pulley
70 712-0700 Flange Nut 9/16-18
71 718-0758A Pulley Hub
72 683-04055 Transmission Torque Bracket
73 683-04130 Idler Bracket
74 710-0227 AB Screw #8-18 x 0.5
75 725-1644 Spring Switch
76 750-0736 Shoulder Spacer
77 710-0514 Hex Bolt 3/8-16 x 1.0
78 747-04146 Shift Rod
79 726-0320 Insulator Nut Plate
80 736-0242 Bell Washer
81 710-0627 Hex Cap Screw
82 634-0104 Wheel Assembly
634-0070 Rim Assembly
734-0255 Air Valve
734-1730 Tire
83 734-2290A Hub Cap
84 736-0430 Flat Washer
Ref.
No.
Part
No. Description
Models 607 & 608
