MTD 618 - Parts List - Deck and Frame Components

33
Model 618
REF.
NO.
PART
NO. DESCRIPTION
1 747-1130B Deck Stabilizer Rod
2 683-04079 Lift Shaft Assembly
3 711-0332 Clevis Pin,.5 x.78
4 712-0206 Hex Nut, 1/2-13
5 712-0431 Flange Lock Nut, 3/8-16
6 712-3004A Flange Lock Nut, 5/16-18
7 712-3083 Hex Nut, 1/2-13
8 714-0104 Internal Cotter Pin
9 714-0145 Internal Cotter Pin
10 716-0106 E-ring
11 720-0311 Handle Grip
12 732-0874 Torsion Spring
13 732-1184 Extension Spring,.84 x 4.6
14 736-0275 Flat Washer, 5/16
15 736-0921 Lock Washer, 1/2
16 736-3019 Flat Washer,.31 x 1.062 x.134
17 736-3084 Flat Washer,.51 x 1.12 x.06
18 738-0138A Hex Cap Screw, 5/16-18 x.62
19 738-0143 Shoulder Screw, 3/8-16
20 741-0225 Hex Flange Bearing
21 741-0715 Snap Flange Bearing
22 746-0968 Lift Cable, 16.16
23 747-04155 Lift Handle
24 756-1154 Roller Pulley
25 783-0678A Arm Lift
26 783-0720A Deck Stabilizer Bracket
27 710-0260A Carriage Bolt, 5/16 x.62
28 710-0604A Self-tapping Screw, 5/16-18 x.625
29 710-0895 Self-tapping Screw, 1/4-15 x.75
30 731-1990 Lift Lever Cover
31 731-1993 Cover w/ Cup Holder† (Shown)
731-04591 Cup Holder‡
32 736-3078 Flat Washer,.349 x 1.0 x.063
33 783-1010 Deck Lift Plate
34 783-04333 Fender, 4-Style† (Shown)
783-04437 Fender, 7-Style‡
35 783-1489 Seat Mounting Bracket
36 710-1268 Screw, #10-16 x.375
37 712-3027 Hex Flange Lock Nut, 1/4-20
38 720-0309A Seat Adjuster Grip
39 731-04074 Spacer
40 732-0499 Compression Spring,.41 x 1.5
41 710-0726 Self-tapping Screw, 5/16-18 x.625
42 736-0204 Flat Washer,.344 x.62 x.03
43 738-0137A Shoulder Screw,.340 x.285,1/4-20
44 738-0966 Shoulder Screw,.50 x.50, 3/8-16
45 783-0611 Seat Stop
46 783-0738A Seat Pivot Bracket
47 783-0739 Seat Adjustment Lever
48 783-0753 Seat Adjustment Selector
49 757-04012 High Back Seat
757-04011B Medium Back Seat
50 735-0656 RH Foot Pad, Rubber (4-Style Fender)
51 735-0657 LH Foot Pad, Rubber (4-Style Fender)
52 714-0111 Cotter Pin
54 783-0209C Seat Lift Bracket
55 710-0870 Hex Head Washer Screw, 3/8-16 x.625
56 783-04081A Seat Pivot Bracket, Manually Adjusted
57 735-0672 RH Foot Pad, Rubber (7-Style Fender)
58 735-0673 LH Foot Pad, Rubber (7-Style Fender)
59 720-04009 Knob, 3/8-16
60 736-0331 Cupped Washer,.39 x 1.12
61 726-3046 Ratchet Clip
62 738-0296 Shoulder Screw,.437 x.286
63 726-0201 Speed Nut,.3125
64 736-0160 Flat Washer,.531 x.93
65 738-04012 Shoulder Screw
REF.
NO.
PART
NO. DESCRIPTION
†
Models equipped with a 4-style fender can accept the cover w/ cup holder.
‡
Models equipped with a 7-style fender can accept only a cup holder.
NOTE: Tractor features vary by model. NOT all parts listed above and pictured on the previous page are standard equipment.
