MTD Series 080 - Page 19

19

 Description
1. 710 -1205 Eye Bolt
2. 720-0279 Wing Nut
3. 747-1161A Blade Control Handle
4. 749-1092A Upper Handle
5. 746-0957 Control Cable
6. 749-04037 Lower Handle
7. 725-0157 Cable Tie
8. 787-01097 Deck Assembly, 22”
9. 710-0654A TT Screw, 3/8-16 x 1.0
10. 748-0376C Blade Adapter
11. 742-0642A Standard Blade, 22”
742-0742A† Mulching Blade, 22”
12. 736-0524B Blade Bell Support
13. 710-1044 Screw, 3/8-24 x 1.5
14. 712-04065 Lock Nut, 3/8-16
15. 741-04242 Height Adjuster Bearing
16. 687-02342 Pivot Arm
17. 731-1034B Hinged Chute Deector Assembly
18. 736-0741 Bell Washer, .760 OD x 1.25 OD

 Description
19. 7 38 -117 2 Shoulder Screw
20. 734-1988 Front Wheel, 7 x 1.8, Bar
21. 710-0599 TT Screw, 1/4-20 x .5
22. 736-0270 Bell Washer, .265 ID x .75 OD
23. 710-0216 Screw, 3/8-16 x .75
24. 738-1173 Shoulder Screw
25. 734-1987 Rear Wheel, 8 x 1.8, Bar
26. 682-3064 Handle Bracket Assembly, RH
— 682-3065 Handle Bracket Assembly, LH
27. 720-04072 Star Knob
28. 731-04019 Trailshield
29. 17098 Hinge Clip
30. 710 -1174 Carriage Bolt, 5/16-18 x 2
31. 720-0426 Knob
32. 732-1026 Lever
33. 732-1014 Torsion Spring
34. 17032A Chute Hinge
35. 747-0710 Hinge Pin
36. 631-04045† Mulching Bae
† If Equipped
Model Series 080
