To Next PageTo Next PageWhat to do if the MTI Furnace controller panel SV shows “HiaL”?
If the controller panel SV displays “HiaL”, it indicates that the furnace temperature exceeds 1500 degrees. You should cool the furnace down and investigate the reason for the excessive temperature.
What to do if the MTI GSL-1500X-OTF has no current or voltage during heating?
If there is no current or voltage during heating, the heating element may be broken. Locate the damaged heating element and replace it.
Why is the green power indicator off, but the red open circuit indicator on, in my MTI GSL-1500X-OTF Furnace?
If the green power indicator is off while the red open circuit indicator is on, the fuse in the main power circuit may be broken. Open the furnace front panel and replace the fuse.
How to fix 'OraL' on the MTI GSL-1500X-OTF Furnace controller panel SV?
If the controller panel SV displays “OraL”, it means the thermocouples are broken. Replace the thermocouples (S type).
What to do if the MTI Furnace power and heating element are fine, but the furnace can’t be controlled by program?
If the power and heating element are functioning correctly, but the furnace cannot be controlled by the program, the controller or related circuit may be damaged. Check the controller for any issues. If the controller seems fine, further investigation by the manufacturer is needed to identify the root cause.
How to fix an MTI Furnace with no power indication and an open power lock?
If there is no power indication and the power lock is open, the fuse in the control panel may be broken. Check the control panel and replace the fuse.
Key information and notes for users before operating the equipment.
Crucial safety warnings regarding electrical shock, burns, and physical injuries.
Overview of the GSL-1500X-OTF furnace series and its capabilities.
Detailed technical specifications for the GSL-1500X-OTF furnace model.
Description of the furnace's physical components and control panel.
Procedures and requirements for installing the furnace system.
Guidelines for placing and operating the furnace in a suitable environment.
Instructions for correctly installing the tube and vacuum sealing flanges.
Requirements and guidance for connecting the furnace to the power supply.
Steps for safely loading and unloading materials into the furnace.
Instructions for connecting and operating the vacuum system.
Connecting and controlling the gas flow system for furnace operation.
Specifications and structure of the 518P temperature controller.
Guidance on setting up and operating the temperature controller.
How to switch between different display modes on the temperature controller.
Example of setting up a multi-segment temperature control program.
Visual representation of the temperature control program with 6 segments.
Overview of key parameters for temperature controller configuration.
Explanation of the M5 parameter's role in PID calibration and integral work.
Description of parameter P's effect on proportion and differential functions.
Definition of parameter 't' and its impact on PID functions.
Explanation of control types and parameter lock settings.
Steps for navigating and modifying parameters in the controller.
Procedures for auto-tune and manual tuning of PID parameters.
Common problems and their solutions for the furnace system.
Regular maintenance tasks and important cautions for furnace care.
Requirements and information regarding AC power connection for the furnace.
General| Model | GSL-1500X-OTF |
|---|---|
| Type | Tube Furnace |
| Max Temperature | 1500°C |
| Power Supply | 220V AC, 50/60Hz |
| Heating Element | MoSi2 |
| Control System | PID Controller |
| Heating Zones | Single or Multi-zone options |
| Tube Diameter | 60mm |
| Tube Material | Quartz tube or Alumina tube |
| Heating Rate | ≤ 20°C/min |
| Cooling Rate | Natural Cooling |
| Atmosphere Control | Yes, with gas inlets and outlets |
| Vacuum Capability | Yes, with optional vacuum pump |
| Heating Zone | One |
| Thermocouple Type | Type B |
| Chamber Size | 60mm (outer diameter) x 1000mm (length) |
| Chamber Dimensions | 60mm (outer diameter) x 1000mm (length) |
