400 amp size in typical enclosure with location of customer connections
Normal
Power
Connections
Emergency
Power
Connections
Manual Override
LOAD
Power
Connections
ATS-22AG Control
and position indicators
Remote Start
plus
Alarm connection
Active for 60 sec ONLY
When ATS is on Generator
