MTS Systems FlexTest GT User Manual

MTS 793 Controller Hardware
FlexTest GT Controller Connections
156
Cable specifications • Connector: 25-contact, type D, male, EMI
• Backshell: EMI, metalized plastic
• Twisted pairs with overall braided shield. Braided shield is
terminated to conductive backshell at the chassis.
Jumper plug Use MTS jumper plug PN 100-079-233.
Input 1
Station
Interlock
Input 2
Station
Interlock
+5 V
Input 3
Station
Interlock
Input 4
Station
Interlock
7
J8 From
External Device
+5 V
To
Chassis
0 V
1
2
14
15
4
5
17
18
7
8
20
21
10
11
23
24
+5 V
+5 V
logic
driver
relay
contacts
