MTS 793 Controller Hardware
Installing the 493.02 Chassis (FlexTest SE)
Installation
48
Installing the 493.02 Chassis (FlexTest SE)
This section describes how to install the MTS FlexTest 493.02 chassis
and connect it to your system components.
Contents Installing the Plug-in Modules 41
VMEbus Modules 49
Chassis Installation Options 50
Connecting Electrical Power 52
Installing the Handle Kit 56
Installing the Plug-in Modules
This section describes how to install the plug-in modules into the
chassis. The modules plug into a backplane connector and are secured
to the chassis with a screw at the top and bottom of the faceplate.
The plug-in modules contain static-sensitive components.
Improper handling of the module can cause component damage.
Be sure to follow these precautions when handling modules:
• Turn off electrical power before installing or removing a module.
• Use a static ground strap to ground yourself to the chassis ground
before touching the chassis or a module.
• Keep unused modules in conductive bags. Also be sure you are
grounded when removing a module from a conductive bag.
• Handle modules with their front panel or circuit card edges. Do not
touch any circuit card components, pins, or circuit connection points.
CAUTION
