MTS 793 Controller Hardware
FlexTest IIm Controller Connections
190
Sample conditioner
output connections
This table shows connector assignments for various MTS products you
can use with your FlexTest IIm controller.
Task 2 Create your configuration file with Station Builder.
Using Station Builder, define controller resources to provide
programming to an external controller.
Refer to “How to Create Your Station Configuration File” and “Creating
Program Channels” in the MTS 793 Control Software manual for more
information.
Task 3 Adjust the signals with Station Manager.
Adjust Program
Signal
Adjust the outgoing program signal for the required external controller
channel.
Refer to “How to Adjust Program Output Signals” in the MTS 793
Control Software manual for more information.
Conditioning Sensors with Other MTS Products
MTS P
RODUCT SENSOR OUTPUT
Model 408.81 Testing Panel/
Model 408.82 DC Conditioner
Sensor output is available at the rear-panel connector
J201 or J202.
Model 409.81C Temperature Controller
Temperature output (via an analog signal) is available
at rear-panel connector J1.
Model 448.82/85 Test Controller with
Model 448.21/22 AC and DC Conditioners
Sensor output is available at rear-panel connector
J335.
Ensure sensor conditioners are set as follows:
X1: 2&3
X2: 2&3
Model 458.10/20 MicroConsole
®
with
Model 458.11/12/13/14 AC and DC
Controllers
Sensor output is available at the MicroConsole rear-
panel connector Jx03. Connector Jx03 represents the
module location (J100–J600).
MicroConsole jumper Jx00 should be set to 1&2
(standard setting).
