29
The MPA amplifier does not care where the earth ground is. This example is a delta
secondary.
Delta Secondary
L2 (NEUTRAL)
GND
L
1
(
H
O
T
)
L3 (HOT)
EARTH
GROUND
In this example L2 became ground.
