28
Grounding
The ac supply source for the amplifier is supposed to be bonded to earth ground.
Typical WYE Secondary
L
1
(
H
O
T
)
L2 (HOT)
L3 (HOT)
GND
EARTH
GROUND
Typical Delta Secondary
EARTH
GROUND
L2 (HOT)
GND
L
1
(
H
O
T
)
L3 (HOT)
These are the two most typical transformer configurations and failure to ground these
properly could void warranty.
