7
Parameter Specification
Encoder Signals:
Resolution
Accuracy:
Resolver Cable Length:
15 foot
25 foot
50 foot
100 foot
250, 360, 400, 500, 720, 1000, 1024, 2000 and 4096 lines
Max. Error:
±20 minutes
±20 minutes
±30 minutes
±40 minutes
Weight:
MPA-05/09-460
MPA-15-460
MPA-25/35/50-460
MPA-75/100-460
12 lbs. max
14 lbs. max
20 lbs. max
45 lbs. max
Motor Inductance:
For all 460 volt products, the inductance line-to-line must be
no less than 4mH.
IND-100-.5mH
IND-25-460-2mH
One inductor in each line is typical. The turn ON times of the
power switches can cause catastrophic destruction of
motors. Inductors in RST of the motor leads limit the rise time
and preserve the motor. All 460 volt motors should have
inductors.
