MPA-05/09/15/25/35/50-460 Mechanical Footprint

1.0

.31

13.6

14.6

FRONT VIEW

.5 RECOMMENDED

11.25

SIDE VIEW

Summary of Amplifier Dimensions

Model A (inches) B (inches) C (inches)

MPA-05/09/15-460 6.5 4.5 .53

MPA-25/35-460 8.5 6.5 .53

MPA-50-460 8.5 6.5 2.2

NOTE

If front cover is attached, additional

clearance of .2 should be allowed.
