MPA-75/100-460 Mechanical Footprint

SIDE VIEW

1.64

11.63

.5 RECOMMENDED

15.2

5.5

13.6

14.6

3.15

.31

NOTE

FRONT VIEW

NOTE

If front cover is attached, additional

clearance of .2 should be allowed.
