MTX.COM
2
PRODUCT INFORMATION
Model #
Serial #
Dealer’s Name
Date of Purchase
IN THE BOX
• Speaker and Enclosure
• Brackets
• For mounting the bracket base to the enclosure
• (8) M6-1.0x14mm stainless steel Hex Bolt
• (8) M6 at washer stainless steel
• (8) M6 split lock washer stainless steel
• For tightening the bracket strap to the base
• (2) M6-1.0x50mm stainless steel Hex Bolt
• (2) M6 serrated ange lock nut stainless steel
INTRODUCTION
Thank you for purchasing this MTX Audio cage mount speaker pod. This high performance speaker
features all-weather construction designed to deliver exceptional sound quality and volume for high
output systems for those that love to hear their music wherever they are. Additionally, each speaker
enclosure includes a RGB LED light kit that enables customization of the speaker lighting color on the
grille. Congratulations and enjoy the ultimate audio experience with MTX!
FEATURES
• Integrated RGB LED Lighting
• Includes Rotating Brackets for 1.5", 1.75", and 2" Bars
• ABS Impact Resistant Enclosure and Grille with UV Inhibitor
• Polypropylene Woofer and Mylar Dome Tweeter
• Tested 500 Hrs to ASTM B117, D4329 Standard
• IP67 Rated for Outdoor Use
SPECIFICATIONS
RMS Power Handling: 50-Watts
Peak Power Handling: 100-Watts
Sensitivity (2.83V/1m): 89.9dB
Sensitivity (1W/1m): 85.6dB
Frequency Response: 70Hz - 20kHz
Impedance: 4Ω
Fits Bars 1.5", 1.75", and 2"
WIRE COLOR
Grey / Black: +/- speaker wire
Black / Red / Green / Blue: +/ground speaker illumination
