Action 34. Draining the deposit from
the fuel fine filter
Remove the drain plug (1) and drain de-
posit until clean fuel free of water and
dirt appears traces appear. Tighten the
plug. If necessary, bleed the fuel sys-
tem.
Action 35. Checking the oil level in the
transmission
Check oil level by using oil-measuring
rod (1) on the left side of the gearbox.
The normal working oil level shall be be-
tween the upper and lower marks on the
probe.
NOTE: If your tractor is equipped with f
speed reducer, check the oil level
against the check plug (2) located on the
right side of the gearbox. The normal
working oil level shall be at the lower
edge of the threaded opening of the plug
(2).
If you have to correct oil level, remove
the plug (3) on the upper cover of the
gearbox and add oil to the level.
